OEM-spec 24212-20-20RW ORFS Female Swivel Spiral Hose Fitting
SKU 24212-20-20RW
In stock: 4 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
The 24212-20-20RW is an ORFS female flat seal swivel spiral hose fitting, conforming to ISO 12151-1 / SAE J516. OEM-spec replacement — this is a quality OEM-spec hydraulic hose fitting manufactured to industry standards. Manufactured from zinc-plated carbon steel for corrosion resistance in hydraulic systems. Stocked in Kelowna, BC and available for shipping across Canada.
Specifications
| Part Number | 24212-20-20RW |
|---|---|
| Type | ORFS Female Flat Seal Swivel Spiral Hose Fitting |
| Standard | ISO 12151-1 / SAE J516 |
| Thread | 1-11/16"-12 UNF ORFS |
| Hose Dash Size | -20 |
| Series | ORFS Swivel Spiral |
| Body Angle | Straight |
| Material | Carbon steel, zinc-plated |
| O-Ring | NBR (Buna-N) |
Fitment
This industry-standard fitting is compatible with hydraulic hose assemblies conforming to ISO 12151-1 / SAE J516. Verify thread size and hose dash size against your hose assembly before ordering.
Cross-References
- Parker 1JS73-20-20
FAQ
What is ORFS?
ORFS stands for O-Ring Face Seal. It uses a flat-faced port with an O-ring groove to provide a highly leak-resistant connection (ISO 12151-1 / SAE J516). It is common in modern heavy-equipment hydraulic systems.
What is the difference between 24211/24212 (straight) and 24241/24242 (45°) and 24291/24292 (90°)?
The numbering denotes body angle: 24211/24212 = straight, 24241/24242 = 45° elbow, 24291/24292 = 90° elbow. Odd suffix (1) = braided hose; even suffix (2) = spiral hose.
Can I use this on braided hose?
The -RW suffix and spiral-hose (even digit) designation indicate this fitting is specified for spiral hose (4SH/4SP). Using it on braided hose may not achieve rated pressure. Verify hose specifications.
Is this in stock in Canada?
Yes, stocked in Kelowna, BC, ships Canada-wide. Same-day dispatch before 2 PM PT.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
