OEM-spec replacement 3052-12-12 ORFS 90° Swivel Elbow | Dash-12
SKU 3052-12-12
In stock: 1 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
This OEM-spec replacement 3052-12-12 is a Male ORFS x Female ORFS swivel 90-degree elbow hydraulic fitting in Dash-12 (3/4" ID) configuration. Stocked at AIM Rentals' Kelowna, BC warehouse and shipped Canada-wide, this fitting meets OEM dimensional and pressure specifications for hydraulic hose assemblies used on heavy equipment and mobile machinery.
The 3052-12-12 Dash-12 ORFS 90° swivel elbow is a Parker 30-Series-style right-angle adapter used to route 3/4" hydraulic lines at 90 degrees. The swivel female end allows 360-degree rotation during installation so the fitting can be precisely oriented without twisting the hose.
Specifications
- Part Number: 3052-12-12
- Type: Male ORFS x Female ORFS swivel 90-degree elbow
- Dash Size: Dash-12 (3/4" hose ID)
- Thread Standard: O-Ring Face Seal (ORFS) both ends
- Material: Steel, zinc-plated (OEM-spec)
- Working Pressure: Rated for high-pressure hydraulic service
- Stocked: Kelowna, BC — ships Canada-wide
Fitment
The 3052-12-12 Dash-12 ORFS 90° swivel elbow fits heavy equipment and mobile machinery hydraulic lines requiring a right-angle ORFS connection in 3/4" hose size. Suitable for excavators, cranes, agricultural tractors, loaders, and industrial hydraulic circuits using Dash-12 ORFS fittings.
FAQ
What does ORFS mean?
ORFS stands for O-Ring Face Seal. The fitting seals against a flat machined face using an O-ring, providing a reliable leak-free connection in high-pressure hydraulic systems.
What is the Dash-12 size?
Dash-12 corresponds to a 3/4-inch hose inner diameter. The dash number multiplied by 1/16 inch gives the nominal ID: 12 × 1/16 = 3/4".
Is this fitting swivel or fixed?
The 3052-12-12 has a swivel female end, meaning the female ORFS side rotates freely. This allows you to align the hose without twisting it, making installation easier and reducing stress on the hose assembly.
Does AIM Rentals ship hydraulic fittings across Canada?
Yes. AIM Rentals ships fittings Canada-wide from Kelowna, BC. Same-day dispatch on orders placed before 2 pm Pacific. Contact sales@rentwithaim.ca to confirm fitment.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
