Adaptall 3060-12-08 ORFS Swivel Straight Reducer | -12 x -08
SKU 3060-12-08
In stock: 4 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Adaptall 3060-12-08 ORFS Swivel Straight Reducer Adapter | -12 x -08
The Adaptall 3060-12-08 is an OEM-spec ORFS (O-Ring Face Seal) swivel straight reducer adapter. It connects a -08 (1/2") male ORFS port to a -12 (3/4") female ORFS swivel in a straight inline configuration, reducing hose diameter. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 3060-12-08
- Series: Adaptall 3060 — ORFS Female Swivel x ORFS Male Straight Reducer
- Side A: -12 (3/4") Female ORFS Swivel (1-3/16-12 UN thread)
- Side B: -08 (1/2") Male ORFS (13/16-16 UN thread)
- Configuration: Straight reducer adapter
- Material: Carbon steel
- Standard: SAE J1453 / ISO 8434-3
Fitment
Compatible with hydraulic hose assemblies on heavy equipment wherever a straight -08 to -12 ORFS reducer is needed at pumps, motors, valves, and cylinders.
FAQ
What does the 3060-12-08 part number mean?
The Adaptall 3060 series designates ORFS female swivel x ORFS male straight reducer adapters. -12 is the female swivel dash size (3/4"), and -08 is the male thread dash size (1/2").
How does this differ from 3060-08-12?
The 3060-12-08 and 3060-08-12 are the same reducer connection but with the swivel on the -12 side vs. the -08 side, allowing different hose routing flexibility.
What seal does it use?
ORFS (O-Ring Face Seal) per SAE J1453 / ISO 8434-3 — O-ring face seal for leak-free high-pressure connections.
Does AIM Rentals ship Canada-wide?
Yes. This fitting is stocked in Kelowna, BC and ships Canada-wide.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
