OEM-spec MCWA-90X105X6 Hydraulic Seal | 90×105×6 mm Metric Link Pin
SKU 90X105X6
In stock: 3 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
OEM-spec MCWA-90X105X6 Hydraulic Seal | 90×105×6 mm Metric Link Pin
The MCWA-90X105X6 is an OEM-spec metric hydraulic wiper/rod seal with dimensions 90 mm inner diameter × 105 mm outer diameter × 6 mm cross-section. This seal is used in excavator link pin applications on Caterpillar, John Deere, and Komatsu equipment. Stocked in Kelowna, BC and ships Canada-wide. Always confirm seal dimensions and groove specifications before installing.
Specifications
- Part Number: MCWA-90X105X6 (SKU: 90X105X6)
- Type: Hydraulic Link Pin Seal (Metric)
- Inner Diameter: 90 mm
- Outer Diameter: 105 mm
- Cross-Section / Width: 6 mm
- Application: Excavator link pin seal groove
- Material: Aftermarket polyurethane/NBR (OEM-spec)
Cross-References
- CC-90X105X6-NBR
- OAS-90X105X6-NBR
Fitment
- Caterpillar excavator link pin applications (confirm by groove dimensions)
- John Deere excavator link pin applications (confirm by groove dimensions)
- Komatsu excavator link pin applications (confirm by groove dimensions)
Verify the link pin bore and groove dimensions on your specific machine before ordering.
FAQ
How do I verify the MCWA-90X105X6 seal is the right fit?
Measure the link pin housing bore (should be 105 mm OD), the shaft (should be 90 mm ID), and the groove width (6 mm). Match these measurements to the seal dimensions above.
Is this an OEM seal or aftermarket?
This is an OEM-spec aftermarket replacement seal manufactured to meet or exceed OEM dimensions and material specifications for Caterpillar, John Deere, and Komatsu link pin seals.
Where can I get this seal in Canada?
AIM Rentals stocks the MCWA-90X105X6 seal in Kelowna, BC and ships Canada-wide.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["Caterpillar excavator link pin applications","John Deere excavator link pin applications","Komatsu excavator link pin applications"] | |||
