Genuine Hyundai 24L1-05100 Relay | 6P Cabin Electrical | Wheel Loader and Excavator
SKU 24L105100
In stock: 1 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Genuine Hyundai 24L1-05100 Relay, 6 Prong Cabin Electrical
Small relay sealed inside a Genuine Hyundai Construction Equipment bag with the blue Genuine HYUNDAI wordmark and INSTRUCTIONS printing along the seam. The factory label reads part number 24L1-05100, description RELAY (6P), quantity 1 EA, batch RG21 C1 QVB1, box G03B05A2, box tag H1706. Country of origin printed on the label: MADE IN KOREA, REPUBLIC OF. A second bag of this same SKU came off the shelf beside it with a Woodland Equipment pick ticket, quantity 2 EA on that bag, RELAY, batch B0101L05.
The number is well documented. Modern Shop lists Hyundai OEM Relay for 24L1-05100 and notes it is superseded by 21WD-01240 for new orders. The Hyundai HCE parts index lists it as RELAY-5P and shows it on a wide fitment list: HL720-3, HL730-7, HL730-7A, HL730-9, HL730-9A, HL730-9S, HL730-9SB, HL730TM-7, HL730TM-9, HL740-3ATM, HL740-7, HL740-7A wheel loaders, R110-7 and R140W-9 excavators, and 110D-7A, 110DE, 180DE, 250DE and 50D-9 forklifts. Note the discrepancy: our factory label reads 6P and the third party index calls it 5P. This is not an error on our part, it is what the two sources print. Check your existing relay pin count before installing.
What you are buying is one factory sealed relay in the bag we photographed. It fits on the 24 volt cabin electrical circuit, typically horn, cabin harness or console. It is the same relay body Omron produces for Hyundai on this SKU, so the switching profile is the OEM one, not an aftermarket approximation.
On price, the working retail basis is 29 USD, the last public transaction price recorded on the Hyundai HCE parts index for this exact number. Converted at today's Bank of Canada rate around 1.38 and run through our all in formula with the small parcel freight allowance, that lands at the sticker shown. If Modern Group or your local Hyundai dealer is quoting the newer 21WD-01240 supersession, ask us before you order and we will confirm the current in stock supersession too.
What is on the label
- Genuine Hyundai Construction Equipment bag, blue Genuine HYUNDAI wordmark
- Factory label: part number 24L1-05100
- Description: RELAY (6P)
- Quantity: 1 EA. Batch: RG21 C1 QVB1, G03B05A2, H1706
- Country of origin: MADE IN KOREA, REPUBLIC OF
Fitment
- Make: Hyundai
- Wheel loaders: HL720-3, HL730-7, HL730-7A, HL730-9, HL730-9A, HL730-9S, HL730-9SB, HL730TM-7, HL730TM-9, HL740-3ATM, HL740-7, HL740-7A
- Excavators: R110-7, R140W-9
- Forklifts: 110D-7A, 110DE, 180DE, 250DE, 50D-9
- Hyundai part number: 24L1-05100. Superseded by 21WD-01240
Stocked one unit in Prince George, BC. Ships free Canada wide, no brokerage surprise. Price is all in.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
