Genuine Danfoss 26013-LZC Series 26 Aluminum Gear Pump | SAE A 2-Bolt
SKU 26013LZC
In stock: 1 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Genuine Danfoss 26013-LZC Series 26 Aluminum Gear Pump
Genuine Danfoss Series 26 aluminum gear pump, part number 26013-LZC (also written 26013LZC). This pump is a compact, high-efficiency unit designed for mobile and industrial hydraulic systems including agricultural machinery, material handling, construction, and lift trucks. Formerly catalogued under Eaton/Cessna. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 26013-LZC
- Series: Series 26 Aluminum Gear Pump
- Displacement: 1.87 cu in/rev (30.6 cc/rev)
- Rated Speed: 3000 RPM (max)
- Flow @ Rated Speed: 24.1 US GPM
- Max Continuous Pressure: 3000 PSI
- Max Intermittent Pressure: 3250 PSI
- Shaft: 3/4" keyed, 1-1/4" extension
- Mounting: SAE A (2-bolt), SAE Flange Series 82-2
- Suction Port: SAE-16 side port (1.3125-12 UN-2B SAE O-Ring)
- Pressure Port: SAE-10 side port (0.875-14 UNF-2B SAE O-Ring)
- Rotation: Left-hand (CCW)
- Housing Material: Aluminum
- Weight: 7.5–8.0 lb
Fitment
The Danfoss Series 26 gear pump is suitable for a wide range of mobile and industrial hydraulic applications including:
- Agricultural tractors and harvesters
- Lift trucks and forklifts
- Fan drive systems
- Compactors and sweepers
- Machine tool auxiliary circuits
- Steering circuits
- Rotary and reel mowers
Cross-References
- 26013-LZC (Danfoss hyphenated format)
- 26013LZC (no-hyphen format)
- Eaton/Cessna 26013-LZC (former catalog reference)
FAQ
Is this a genuine Danfoss pump?
Yes. The 26013-LZC is a genuine Danfoss Series 26 aluminum gear pump, confirmed in the Danfoss PowerSource catalog and stocked at authorized distributors including Applied Industrial Technologies and SunSource.
What applications is this pump suited for?
The Series 26 is a versatile pump for medium-pressure hydraulic circuits in mobile equipment (lift trucks, agriculture, construction) and industrial machinery. Its aluminum housing keeps weight low while delivering up to 24.1 GPM at 3000 RPM.
Is this pump reversible?
The 26013-LZC ships as left-hand (CCW) rotation. Danfoss Series 26 pumps are field-reversible by re-orienting internal components. Consult the Danfoss Series 26 service manual for reversal procedure.
Where is this stocked?
In stock in Kelowna, BC. Orders ship same business day (before 2 PM Pacific). Shipping included Canada-wide on most orders.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
