DDS 20023015SF Rotary Shaft Seal | 200x230x15 mm Single Lip
SKU 20023015
In stock: 2 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
DDS 20023015SF Rotary Shaft Seal
OEM-spec rotary shaft seal, part number 20023015SF, manufactured by DDS. This is a single-lip oil seal with spring (SF = single lip with spring), nominal dimensions 200 mm inner diameter x 230 mm outer diameter x 15 mm width. Cross-references SKF 20023015 SCV and comparable heavy-duty shaft seals. Suitable for large-bore hydraulic and drivetrain applications. Stocked in Kelowna, BC and ships Canada-wide.
Specifications
- Part Number: 20023015SF (also 20023015)
- Type: Rotary Shaft Seal — Single Lip with Spring
- Inner Diameter: 200 mm
- Outer Diameter: 230 mm
- Width: 15 mm
- Brand: DDS
- Stocked: Kelowna, BC — ships Canada-wide
Fitment
Large-bore 200 mm shaft seals are used in heavy equipment drivetrain, hydraulic cylinder, and reduction gear applications. Please confirm your equipment requires a 200x230x15 mm shaft seal before ordering.
Cross-References
- 20023015SF
- 20023015 (base number)
- DDS 20023015SCV (variant)
FAQ
What does SF mean in DDS part numbers?
SF stands for single-lip seal with spring. The spring maintains lip contact pressure on the shaft for improved oil retention across a range of operating conditions.
What equipment uses a 200x230x15 mm seal?
These large-diameter shaft seals are typically found in heavy equipment transmissions, final drives, wheel hubs, and large hydraulic cylinders. Confirm your seal dimensions before ordering.
How do I measure my existing seal?
Measure inner diameter (ID), outer diameter (OD), and width of the old seal. Confirm ID=200 mm, OD=230 mm, W=15 mm to match 20023015SF.
Can this be shipped to me in Canada?
Yes. This part ships from Kelowna, BC to all Canadian provinces and territories.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
