Genuine Fleetguard AF25620 Air Filter | Secondary Inner Element | Caterpillar, Volvo
SKU AF25620
In stock: 2 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
The Genuine Fleetguard AF25620 is a secondary (inner/safety) Magnum RS air filter element stocked in Kelowna, BC and available with Canada-wide shipping. Used as the inner safety element paired with the outer primary AF25619. Engineered by Fleetguard (Cummins Filtration) to protect engines from airborne contaminants during primary element replacement.
Specifications
- Brand: Fleetguard (Cummins Filtration)
- Part Number: AF25620
- Filter Type: Air, Secondary Magnum RS (inner/safety element)
- Companion Outer Primary Element: AF25619
- Overall Length: 563 mm (22.17 in.)
- Outside Diameter (Largest): 179 mm (7.05 in.)
- Inside Diameter (Largest): 137 mm (5.39 in.)
- Flow Direction: Outside In
- Warranty: 1 Year / 100,000 operating hours
Fitment
The AF25620 is the secondary inner safety element confirmed to fit equipment using the AF25619/RS3827 filter housing, including:
- Caterpillar 3406C, 3456, C15, C18, PM3456 (OEM 189-0202)
- Volvo (OEM 11033999)
- Euclid R32, R32C (Volvo TD122 engine)
- Hyundai (11LQ-40120)
Cross-References
- Baldwin: RS3827
- Donaldson: P777875
- Luber-Finer: LAF8766
- Volvo OEM: 11033999
- Caterpillar OEM: 189-0202
- Hyundai OEM: 11LQ-40120
Frequently Asked Questions
Is AF25620 the inner or outer filter?
AF25620 is the inner (secondary/safety) element. The outer primary element for this housing is AF25619. Both should be available at service time; the inner element protects the engine when the outer is removed.
Is this a genuine Fleetguard filter?
Yes. Genuine Fleetguard (Cummins Filtration) — engineered to original OEM specifications, not an aftermarket alternative.
Does this fit Caterpillar C15/C18 engines?
Yes. The AF25620 replaces Caterpillar OEM part 189-0202 used on the 3406C, 3456, C15, and C18 engine platforms.
Can I order from outside BC?
Yes. AIM Rentals ships Canada-wide from Kelowna, BC. Orders before 2:00 PM Pacific typically ship the same business day.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
