Genuine Hyundai HCE 39Q6-11150 Swash Plate | HX220L R210LC-9

Genuine Hyundai HCE 39Q6-11150 Swash Plate

The Hyundai HCE 39Q6-11150 (also catalogued as 39Q611150) is a genuine OEM swash plate for the Hyundai HCE swing motor assembly. The swash plate is a precision internal component of the swing motor that determines the displacement angle of the pistons, directly governing swing speed and torque. It is a critical wear item during swing motor rebuild and overhaul. Genuine Hyundai HCE part, stocked in Kelowna, BC and ships Canada-wide.

Specifications

• Part Number: 39Q6-11150 / 39Q611150
• Type: Swash Plate (Plate-Swash)
• Assembly: Swing Motor
• OEM: Genuine Hyundai HCE
• Stocked: Kelowna, BC, Canada

Fitment

• Hyundai Wheeled Excavator: HW210
• Hyundai F-Series Excavator: HX160L, HX180L, HX220L, HX220NL, HX235L, HX260L, HX300L, HX330L, HX480L, HX520L
• Hyundai 9-Series Excavator: R160LC-9, R160LC-9A, R160LC-9S, R160W-9A, R170W-9, R180LC-9, R180LC-9A, R180LC-9S, R180W-9A, R180W-9S, R210LC-7A, R210LC-9, R220LC-9A, R250LC-9, R300LC-9S, R520LC-9S

Cross-References

• Hyundai HCE Assy: XJBN-00667 (Swash Plate Assy)

FAQ

What is a swash plate in a swing motor?

The swash plate is an angled disc inside the axial piston swing motor. As it rotates, it forces pistons in and out of the cylinder block, creating hydraulic flow. Its angle determines the motor displacement and swing torque.

When should the swash plate be replaced?

Replace the swash plate during a swing motor rebuild when scoring, wear flats, or pitting are found on the sliding face, or when swing speed/power has degraded and other components are in spec.

Is 39Q6-11150 the correct part number?

Yes — 39Q6-11150 and 39Q611150 are the same Hyundai HCE OEM part number (hyphens are omitted in some catalogs). Verify against your excavator serial number and parts manual before ordering.

Where is this stocked in Canada?

AIM Rentals stocks the 39Q6-11150 in Kelowna, BC and ships Canada-wide.
