Winner by Danfoss 26792-12-12 90° JIC Female Spiral Hose Fitting | -12 High Pressure
SKU 26792-12-12
In stock: 6 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner by Danfoss 26792-12-12 90° JIC Female 74° Cone Seat Spiral Hose Fitting
The Winner by Danfoss 26792-12-12 is an OEM-spec 2-piece crimp 90° JIC female swivel hose fitting for -12 (3/4" ID) spiral hydraulic hose. Rated up to 4,800 PSI working pressure, it features a 74° cone seal and a 1-1/16"-12 UN thread. The 26792 series is specifically designed for multi-wire spiral hose (26792 = spiral series; 26791 = braided series). Manufactured to ISO 12151-5 / SAE J516. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 26792-12-12
- Series: Winner 26792 (2-Piece, Spiral Hose)
- End Type: JIC Female 74° Cone Seat, 90° Elbow Swivel
- Hose Dash Size: -12 (3/4" ID spiral hose)
- Terminal End Dash Size: -12
- Thread Size: 1-1/16"-12 UN
- Working Pressure Max: 4,800 PSI (330 bar)
- Inside Diameter: 0.590 in (15.0 mm)
- Material: Carbon steel, zinc plated
- Construction: 2-piece crimp, spiral hose (skive)
- Standard: ISO 12151-5 / SAE J516
- Brand: Winner by Danfoss (OEM-spec)
Fitment
Designed for use with -12 (3/4" ID) multi-wire spiral hydraulic hoses. Compatible hoses include Winner/Danfoss 2755, GH493, and GH506 spiral hose series, and equivalent SAE 100R9, 100R12, 100R13, and 100R15 spiral hoses. Suitable for high-pressure circuits in heavy construction equipment, mining, and industrial hydraulic systems.
Cross-References
- 26792-12-12Z — Winner by Danfoss standard carbon steel with Cr3+ zinc plate (same fitting)
- 26791-12-12Z — braided hose series equivalent (26791 braided)
- 26792-12-10Z — reduced end (12 x 10) variant in spiral series
FAQ
What is the difference between 26791 and 26792 series?
The 26791 series is for braided hydraulic hose (SAE 100R1/R2 type); the 26792 series is for spiral (multi-wire spiral) hose (SAE 100R9/R12/R13/R15 type). The spiral series handles higher working pressures. Match the fitting series to your hose construction for a proper crimp.
What spiral hoses are compatible with the 26792-12-12?
Compatible with -12 spiral hoses including Winner/Danfoss 2755, GH493, GH506, and equivalent SAE 100R9/100R12/100R13/100R15 hoses. Always confirm crimp dimensions with your hose crimping equipment specifications.
What is the maximum working pressure?
The 26792-12-12 is rated at 4,800 PSI (330 bar) maximum working pressure per Danfoss PowerSource specifications.
Where is this fitting stocked?
In stock at AIM Rentals, Kelowna, BC. Orders placed before 2 PM Pacific ship same business day. Ships Canada-wide.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
