OEM-spec 87692-12-12RW SAE Code 62 90° Flange Elbow | 3/4in x 3/4in
SKU 87692-12-12RW
In stock: 3 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
The 87692-12-12RW is an OEM-spec replacement SAE Code 62 90-degree hydraulic flange hose fitting, 3/4in (DN20) flange size with a 3/4in (-12) hose bore, rated to 6,000 PSI. Conforms to ISO 12151-3 / SAE J516 / SAE J518 Code 62. Stocked at AIM Rentals' Kelowna, BC warehouse, ships Canada-wide.
Specifications
- Part Number: 87692-12-12RW
- Type: 90-Degree SAE Code 62 Flange Head Hose Fitting
- Flange Size: 3/4in (12 / DN20)
- Hose I.D.: 3/4in (-12)
- Standard: ISO 12151-3 / SAE J516 / SAE J518
- Pressure Rating: SAE Code 62 — 6,000 PSI
- Material: Carbon steel
Fitment
Suitable for SAE J518 Code 62 4-bolt flange ports requiring a 90-degree hose connection from a 3/4in high-pressure port to a 3/4in hose. Used in heavy-duty mobile hydraulic machinery and hydraulic hose assemblies.
Cross-References
Cross-reference: 87692-12-12 (without RW suffix), 87691-12-12 (similar series).
FAQ
- What is the 87692 series?
- The 87692 is the 90-degree elbow version of SAE Code 62 flange hose fittings per ISO 12151-3. For straight Code 62 see 87612; for 45-degree see 87642.
- What pressure is Code 62 rated to?
- 6,000 PSI maximum working pressure for all sizes per SAE J518.
- What does RW suffix indicate?
- RW denotes spiral-wire hydraulic hose compatibility (4SH/4SP). Verify hose end spec before ordering.
- Where is this stocked?
- Stocked at AIM Rentals in Kelowna, BC. Ships Canada-wide. Email sales@rentwithaim.ca for questions.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["Hydraulic hose assemblies","Excavators","Heavy-duty mobile hydraulic machinery"] | |||
