Genuine Littelfuse 24524-10D Starter Relay 24V | XCMG 803670694
SKU 803670694
In stock: 29 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Genuine Littelfuse 24524-10D Starter Solenoid Relay 24V — XCMG Ref 803670694
The Genuine Littelfuse 24524-10D is a plastic-body continuous-duty SPST solenoid relay rated at 24V, 100A continuous (400A inrush). XCMG catalogs this part as 803670694 for use as a motor magnetic switch (power relay) in their excavator electrical systems. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Littelfuse Part Number: 24524-10D
- XCMG OEM Reference: 803670694
- Type: SPST Continuous-Duty Solenoid Relay (Starter/Power Relay)
- Coil Voltage: 24V DC (27V max)
- Current Rating: 100A continuous; 400A inrush (5s ON/5min OFF, 20s max)
- Coil Impedance: 76 ohms
- Contacts: Silver
- Coil Terminals: 2× 0.25" (6.35mm) blade
- Bracket: F-style metal bracket
- Temperature Range: -40°C to +75°C
- Suppression: Diode
Fitment
- XCMG XE135D Excavator
- XCMG XE150 Excavator
- XCMG XE200 Excavator
- XCMG XE210 Excavator
- XCMG XE215 Excavator
- XCMG XE370 Excavator
- XCMG XE470 Excavator
- XCMG XE490 Excavator
Cross-References
- 24524-10D (Littelfuse / Cole Hersee catalog number)
- 803670694 (XCMG OEM reference)
FAQ
What is the 24524-10D relay used for on XCMG excavators?
On XCMG excavators, the 24524-10D functions as a motor magnetic switch (power relay) in the starting circuit. It controls high-current switching for the starter motor or main power distribution.
Is this a genuine Littelfuse part?
Yes. The 24524-10D is a genuine Littelfuse (Cole Hersee) continuous-duty solenoid relay from their plastic-body SPST series.
Does this ship to all of Canada?
Yes. AIM Rentals stocks this relay in Kelowna, BC and ships Canada-wide.
Does this relay have diode suppression?
Yes. The 24524-10D includes integrated diode suppression to protect the control circuit from voltage spikes when the coil is de-energized.
