OEM-spec 20412-18-06RW Hydraulic Fitting | M18x1.5 24° Cone S-Series
SKU 20412-18-06RW
In stock: 7 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
OEM-spec hydraulic hose fitting, part number 20412-18-06RW, metric 24° cone S-series female fitting with M18x1.5 port thread and 3/8" hose end. Manufactured to ISO 12151-2 specification. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 20412-18-06RW
- Type: Hydraulic Hose Fitting — Metric 24° Cone S-Series Female
- Port Thread: M18x1.5 (metric)
- Hose End: 3/8" ID braided/spiral hydraulic hose
- Standard: ISO 12151-2 (24° cone S-series)
- Material: Carbon steel
- Branding: OEM-spec replacement
Fitment
This fitting is compatible with hydraulic systems on construction, agricultural, and industrial equipment using M18x1.5 metric 24° cone S-series ports with 3/8" hose lines. Always verify thread size and hose inside diameter before installation.
FAQ
- What is a 24° cone S-series fitting?
- S-series (also called DIN 2353 or ISO 12151-2) fittings use a 24° flare cone sealing interface. They are widely used in European and Asian hydraulic systems on heavy equipment.
- What hose size does 20412-18-06RW accept?
- The "-06" suffix indicates a 3/8" (Dash 6) inside diameter hydraulic hose. The port thread is M18x1.5.
- Where is this stocked?
- Available in Kelowna, BC, with Canada-wide shipping from AIM Rentals Parts.
- Is this compatible with high-pressure systems?
- S-series metric fittings are rated for high-pressure hydraulic applications. Consult your hydraulic system specifications for maximum working pressure requirements.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
