OEM-spec 20541-36-12RW 45° Metric Female 24° Cone H.T. Hose Fitting
SKU 20541-36-12RW
In stock: 7 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
The 20541-36-12RW is a 45° metric female 24° cone O-ring H.T. braided hose fitting, ISO 12151-2 / DIN 3865. OEM-spec replacement — zinc-plated carbon steel, M36×2, dash-12. Stocked in Kelowna, BC, ships Canada-wide.
Specifications
| Part Number | 20541-36-12RW |
|---|---|
| Type | 45° Metric Female 24° Cone O-Ring H.T. Hose Fitting |
| Standard | ISO 12151-2 / DIN 3865 |
| Thread | M36×2 |
| Hose Dash Size | -12 (3/4") |
| Series | H.T. (Heavy Series, braided hose) |
| Body Angle | 45° |
| Material | Carbon steel, zinc-plated |
| O-Ring | NBR (Buna-N) |
Fitment
Compatible with braided hydraulic hose assemblies (1SN/2SN) with M36×2 port connections. Confirm dimensions before installation.
FAQ
What is the 20541-36-12RW?
A 45° metric female 24° cone O-ring H.T. hose fitting, M36×2, dash-12, ISO 12151-2/DIN 3865. The H.T. (heavy series) is for braided hoses rated to higher pressure than L.T.
What is the difference between 20441 and 20541?
20441 is L.T. light series for standard braided hoses. 20541 is H.T. heavy series for high-pressure braided hose systems.
What does the RW suffix mean?
"RW" indicates zinc-plated finish for standard mineral oil hydraulic systems.
In stock in Canada?
Yes, stocked in Kelowna, BC, ships Canada-wide.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
