Genuine Parker GE15LMEDOMDCF Hydraulic Fitting | XCMG QUY55E Crawler Crane
SKU 803103818
In stock: 2 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
The Parker GE15LMEDOMDCF is a genuine Parker Hannifin Ermeto DIN male stud hydraulic tube fitting. It features a 15 mm tube outside diameter (OD), M18×1.5 male metric thread (ED ISO 9974), and a 24° cone end (EO DIN ISO 8434) connection. The XCMG part number 803103818 cross-references to this Parker fitting, which is stocked for the XCMG QUY55E-00 crawler crane. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Parker Part Number: GE15LMEDOMDCF
- XCMG Cross-Reference: 803103818
- Part Name: Ermeto DIN Male Stud Hydraulic Tube Fitting (Straight)
- Tube OD: 15 mm
- Thread: M18×1.5 (male metric, ISO 9974)
- Connection: 24° EO cone end (DIN ISO 8434-1)
- Series: Light (L)
- Seal Material: NBR
- Material: Steel
- Max Operating Pressure: up to 500 bar (Series L)
- Operating Temperature: -40°C to +250°C (steel)
- Standard: DIN ISO 8434
Fitment
- XCMG QUY55E-00 Crawler Crane (hydraulic system)
Cross-References
XCMG part number 803103818 cross-references to Parker GE15LMEDOMDCF. Available from Parker distributors globally under part number GE15LMEDOMDCF.
FAQ
Is GE15LMEDOMDCF a genuine Parker fitting?
Yes — GE15LMEDOMDCF is a genuine Parker Hannifin Ermeto DIN male stud fitting listed in Parker's official product catalog.
What does the part number code mean?
GE = straight male stud; 15 = 15 mm tube OD; L = Light series; M = metric thread; E = EO 24° cone; DOM = steel material; DCF = NBR seal, light series designation.
Is this fitting suitable for high-pressure hydraulic applications?
Yes — Parker Ermeto Series L fittings are rated for pressures up to 500 bar, meeting DIN ISO 8434 standards.
Where is this stocked?
Stocked in Kelowna, BC. Ships Canada-wide with free shipping included.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["XCMG QUY55E.00 Crawler Crane"] | |||
