Genuine Parker 87392-16-16 Hydraulic Flange Fitting | 90° SAE Code 61 1" Dash-16
SKU 87392-16-16
In stock: 1 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Genuine Parker 87392-16-16 Hydraulic Flange Fitting | 90° SAE Code 61
The Parker 87392-16-16 is a 90-degree SAE Code 61 hydraulic flange fitting for 1-inch (dash-16) braided hose assemblies, rated to 3,000 PSI. The 87392 series is Parker's standard SAE Code 61 90° elbow fitting for medium-pressure hydraulic lines. Stocked in Kelowna, BC and ships Canada-wide.
Specifications
- Part Number: 87392-16-16
- Type: 90° SAE Code 61 Hydraulic Flange Fitting
- Flange Size: 1" (Code 61)
- Hose Dash Size: -16 (1 inch)
- Max Working Pressure: 3,000 PSI (SAE Code 61)
- Application: Braided hydraulic hose assemblies
- Material: Carbon steel, zinc plated
- Dimensions (A×C×D×H): 78 × 44.4 × 38 × 67.5 mm
Fitment
- SAE Code 61 hydraulic flange systems (3,000 PSI rated)
- 1-inch braided hydraulic hose assemblies
- Industrial and heavy mobile equipment hydraulic lines
FAQ
What is the Parker 87392-16-16?
It is a 90-degree SAE Code 61 flange hose fitting with a 1-inch flange port and -16 hose end. It is designed for braided (not spiral) hydraulic hose. For spiral hose, see the 87391 series.
What pressure is SAE Code 61?
SAE Code 61 flanges are rated for 3,000 PSI maximum working pressure. For higher pressures, use SAE Code 62 (6,000 PSI) fittings.
Is this fitting in stock in Canada?
Yes. AIM Rentals stocks Parker 87392-16-16 in Kelowna, BC and ships Canada-wide.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
