OEM-spec 50483-16-12 ORFS Female Swivel 45° Elbow | 1" x 3/4"

SKU 50483-16-12

Only 2 left in BC
$64.50

In stock: 2 available · Ships from Kelowna BC

Verify fitment by part number before ordering.

Verify fitment before ordering

Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.

ShippingOptions shown at checkout
WarehouseKelowna, BC

OEM-spec 50483-16-12 ORFS Female Swivel 45° Elbow Fitting

The 50483-16-12 is an OEM-spec replacement O-Ring Face Seal (ORFS) female swivel 45-degree elbow fitting. It connects a 1" (dash-16) ORFS female swivel end to a 3/4" (dash-12) port or hose end at a 45-degree angle. ORFS 45° elbows are used in hydraulic hose routing where angular clearances are needed. Stocked in Kelowna, BC — ships Canada-wide.

Specifications

  • Part Number: 50483-16-12
  • Type: ORFS Female Swivel 45° Elbow
  • Connection 1: 1" (dash-16) ORFS Female Swivel
  • Connection 2: 3/4" (dash-12) port/hose end
  • Seal Type: O-Ring Face Seal (ORFS)
  • Angle: 45 degrees
  • Material: Carbon Steel
  • Standard: SAE J1453

Fitment

Used in hydraulic hose assemblies on heavy equipment and industrial machinery where 45-degree angular routing is required between a 1" hose and a 3/4" port. Confirm fitment with your technician or email sales@rentwithaim.ca.

FAQ

What is the difference between a 45-degree and 90-degree elbow?

A 45-degree elbow provides a gentler bend angle for moderate directional changes in hose routing, while a 90-degree elbow provides a right-angle turn. The 45-degree reduces pressure drop and allows more flexible routing.

What does 50483-16-12 mean?

50483 designates the ORFS female swivel 45° elbow series; "16" = 1" (dash-16) female swivel end; "12" = 3/4" (dash-12) port end.

Can this ship Canada-wide?

Yes — AIM Rentals ships from Kelowna, BC Canada-wide. Same-day shipping on orders placed before 2:00 pm Pacific Time.

Is this OEM or aftermarket?

This is an OEM-spec replacement fitting meeting SAE J1453 standards for ORFS hydraulic connections.

Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
