SMC CXSM20-35 Dual Rod Compact Cylinder | 20mm Bore 35mm Stroke Double Acting
SKU CSM20X35
In stock: 5 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
SMC CXSM20-35 Dual Rod Compact Pneumatic Cylinder
The SMC CXSM20-35 is a CXS series dual rod compact pneumatic cylinder with 20mm bore and 35mm stroke. Double acting, slide bearing guided, 0.7 MPa maximum pressure, operating temperature -10°C to 60°C. Weight approximately 0.515 kg. Made by SMC Corporation, the global leader in pneumatics. Stocked at our Kelowna, BC warehouse and ships Canada-wide.
Specifications
- Part Number: CXSM20-35 | SKU: CSM20X35
- Series: CXS (Dual Rod Compact)
- Type: Dual Rod Compact Pneumatic Cylinder
- Brand: SMC Corporation
- Bore: 20mm
- Stroke: 35mm
- Action: Double acting
- Bearing: Slide bearing
- Max Pressure: 0.7 MPa
- Temperature: -10°C to 60°C
- Weight: ~0.515 kg
Fitment / Applications
- SMC CXS series pneumatic system applications
- Industrial automation, pick-and-place, guided linear motion
FAQ
What is the difference between CXSM and CXSL SMC cylinders?
CXSM uses slide bearings (for light loads and guided motion), while CXSL uses a linear bushing. The CXSM20-35 is ideal for applications requiring compact guided linear actuation with light to moderate loads.
Is the CXSM20-35 double or single acting?
The CXSM20-35 is double acting — air pressure extends and retracts the rod, making it suitable for both push and pull applications.
What is the maximum operating pressure for the SMC CXSM20-35?
Maximum operating pressure is 0.7 MPa (approximately 102 PSI). Minimum operating pressure is 0.1 MPa.
Where can I buy SMC CXSM20-35 in Canada?
AIM Rentals stocks the CXSM20-35 in Kelowna, BC. Orders ship Canada-wide; same business day on orders before 2:00 pm Pacific.
