Song Chuan 896H-1CH-C Relay 803694539 | XCMG GR3005T Pro
SKU 803694539
In stock: 6 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Song Chuan 896H-1CH-C Relay — XCMG Part 803694539
The Song Chuan 896H-1CH-C is a genuine Song Chuan automotive relay used in XCMG construction equipment. XCMG part number 803694539 references this Song Chuan relay as used in the GR3005T Pro motor grader. The 896H series is a high-power miniature ISO relay rated at 24–28V DC, 20A/15A, in a 1-Form-C (SPDT) configuration. Stocked in Kelowna, BC — ships Canada-wide from AIM Rentals.
Specifications
- XCMG Part Number: 803694539
- Relay Model: Song Chuan 896H-1CH-C
- Type: Automotive Mini Relay — SPDT (1 Form C)
- Coil Voltage: 24–28V DC
- Contact Rating: 20A / 15A
- Series: Song Chuan 896H
- Stocked: Kelowna, BC, Canada
Fitment
- XCMG GR3005T Pro Motor Grader
Cross-References
- Song Chuan 896H-1CH-C
- 896H series (Song Chuan Precision Americas)
FAQ
Is this the genuine Song Chuan relay?
Yes — the 896H-1CH-C is a Song Chuan Precision Americas product and is the confirmed relay used in XCMG GR3005T Pro graders under OEM part number 803694539.
What does SPDT mean on a relay?
SPDT (Single Pole Double Throw / 1 Form C) means the relay has one set of contacts that can switch between a normally-closed (NC) and normally-open (NO) circuit — common in control circuits.
Can I find this relay at an electronics supplier?
Yes — the Song Chuan 896H-1CH-C is also available from electronics distributors (Mouser, etc.) as a standard automotive relay. The XCMG P/N 803694539 is the OEM reference for grader applications.
Does this ship Canada-wide?
Yes — AIM Rentals ships from Kelowna, BC to all Canadian provinces.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["XCMG GR3005TPRO"] | |||
