Tectran 125-6D Air Brake Fitting | Male Pipe Connector 3/8" Tube × 1/2" Pipe
SKU 125-6D
In stock: 4 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Tectran 125-6D Air Brake Fitting | Male Pipe Connector 3/8" Tube × 1/2" Pipe
The Tectran 125-6D is a DOT-approved male pipe connector (push-to-connect) air brake fitting for J844 nylon tubing. It accepts 3/8" OD air brake tubing with a 1/2" NPT male pipe thread outlet. Used in truck and trailer air brake lines and air management systems. Stocked in Kelowna, BC and ships Canada-wide.
Specifications
- Part Number: 125-6D / 89018
- Type: Male Pipe Connector – Air Brake Fitting (Push-to-Connect)
- Tube Size: 3/8" OD
- Thread: 1/2" NPT Male Pipe
- Standard: DOT / SAE J844
- Material: Brass / DOT-approved
Fitment
- Heavy-duty truck air brake systems (3/8" nylon tubing)
- Trailer air brake lines (1/2" NPT connections)
- Commercial vehicle pneumatic tubing systems
Cross-References
- Tectran 89018
- Fairview 125-6D
- PDC HB68-6-8
- Sloan S125-6-8
- Universal Uni-Seal 125-68
FAQ
- What does push-to-connect mean for air brake fittings?
- Push-to-connect fittings allow nylon tubing to be inserted and locked without tools. A grab ring and O-ring seal grip and seal the tube for a reliable, leak-free connection.
- Is this DOT-approved?
- Yes. Tectran 125-6D meets DOT requirements for air brake tubing connections on commercial vehicles.
- What tube size does this accept?
- This fitting accepts 3/8" OD SAE J844 air brake nylon tubing.
- Does this ship Canada-wide?
- Yes. Stocked in Kelowna, BC and ships to all Canadian provinces.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
