Winner Fluid 24212-08-08RW ORFS Female Hose Fitting -08 | 13/16-16 Thread
SKU 24212-08-08RW
In stock: 7 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner Fluid 24212-08-08RW ORFS Female Flat Seat Hose Fitting
The Winner Fluid 24212-08-08RW is an ORFS (O-Ring Face Seal) female flat seat hose fitting for spiral hydraulic hose, conforming to ISO 12151-1 / SAE J516. This -08 hose size fitting features a 13/16"-16 UN thread and is suitable for high-pressure hydraulic hose assemblies in construction, agricultural, and heavy equipment applications. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 24212-08-08RW
- Series: Winner Fluid 24212 (ORFS Female Flat Seat — Spiral Hose)
- Type: ORFS Female Flat Seat Hose Fitting
- Standard: ISO 12151-1 / SAE J516
- Thread: 13/16"-16 UN (ORFS)
- Hose Size: -08 (1/2" ID)
- Material: Carbon steel, zinc plated
- Compatible Hose: 4SP, 4SH, R12 spiral hydraulic hose
Fitment
Universal hydraulic fitting for use in:
- Heavy equipment hydraulic hose assemblies
- Construction machinery hydraulic systems
- Agricultural machinery hydraulic systems
- Industrial hydraulic circuits
Cross-References
- Winner Fluid 24212-08-08 (standard straight variant)
- Danfoss/Eaton Winner 24212 series (-08-08RW)
FAQ
What is the difference between 24211 and 24212?
The 24211 series is for braided hose (1SN/2SN), while the 24212 series is for spiral hose (4SP, 4SH, R12). Choose 24212 when working with higher-pressure spiral hose assemblies.
What does the RW suffix mean on 24212-08-08RW?
The RW suffix denotes a variant of the standard 24212-08-08 fitting, typically indicating a right-angle or wrench-flat configuration. Confirm the end geometry against your hose assembly requirements before ordering.
What thread is the ORFS -08 size?
The -08 ORFS size uses 13/16"-16 UN straight thread with an O-ring face seal. The O-ring sits in a groove on the flat face and seals against the mating surface, providing a leak-free connection at high pressures.
Where is this stocked?
We stock this fitting at our Kelowna, BC facility. Orders ship Canada-wide, typically same business day.
