Winner by Danfoss 26711-08-08Z JIC Female Straight Hose Fitting | -08
SKU 26711-08-08
In stock: 6 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner by Danfoss 26711-08-08Z JIC Female Straight Hose Fitting
Winner by Danfoss 26711-08-08Z is a 2-piece crimp straight hose nipple assembly with a JIC female 37° cone swivel end. Designed for use with -8 braided hydraulic hose in mobile and industrial hydraulic systems. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 26711-08-08Z
- Series: Winner 26711 (2-Piece, Braided Hose)
- End Type: JIC Female 37° Cone Swivel, Straight
- Hose Size: -8 (1/2" ID braided hose)
- Terminal End Size: -8
- Thread: 3/4"-16 UNF
- Material: Carbon steel, zinc plated (Z suffix)
- Construction: 2-piece crimp, no-skive
Fitment
For use with -8 (1/2" ID) single or double wire braid hydraulic hoses (e.g. EC110, EC210, R1AT, R2AT). Suitable for mobile construction equipment, agricultural machinery, industrial hydraulic power units, and hose assembly shops.
Cross-References
- 26711-08-08 (no-suffix base number)
- 26711-08-08Z (zinc plated)
- 26711-08-08ZN (alternate plating code)
- 26711-08-08ZD (alternate plating code)
FAQ
What hose is compatible with the 26711-08-08Z?
This fitting is designed for -8 (1/2" ID) wire braid hydraulic hoses including EC110, EC210, and equivalent SAE 100R1AT/R2AT hoses. Always crimp to Winner/Danfoss specifications using an approved crimp machine.
What does the Z suffix mean?
The Z suffix denotes the standard zinc trivalent chromate plating for corrosion resistance. Other suffix variants (ZN, ZD, etc.) indicate alternate plating specifications.
Where is this stocked?
In stock in Kelowna, BC. Orders ship same business day (before 2 PM Pacific). Shipping included Canada-wide on most orders.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["Hydraulic hose assemblies","Mobile construction equipment hydraulic systems","Industrial hydraulic power systems"] | |||
