Winner by Danfoss 26791-06-06RW 90° JIC Female Fitting | 316Ti Stainless -06
SKU 26791-06-06RW
In stock: 15 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner by Danfoss 26791-06-06RW 90° JIC Female 74° Cone Seat Fitting — 316Ti Stainless Steel
The Winner by Danfoss 26791-06-06RW is an OEM-spec 2-piece crimp 90° JIC female swivel hose fitting for -06 (3/8" ID) braided hydraulic hose in 316Ti stainless steel. The RW suffix designates 316Ti stainless steel construction, providing superior corrosion resistance for marine, wash-down, and aggressive environments. Manufactured to ISO 12151-5 / SAE J516. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 26791-06-06RW
- Series: Winner 26791 (2-Piece, Braided Hose)
- End Type: JIC Female 74° Cone Seat, 90° Elbow Swivel
- Hose Dash Size: -06 (3/8" ID braided hose)
- Terminal End Dash Size: -06
- Thread Size: 9/16"-18 UNF
- Material: 316Ti Stainless Steel (RW suffix)
- Construction: 2-piece crimp, braided hose application
- Standard: ISO 12151-5 / SAE J516
- Brand: Winner by Danfoss (OEM-spec)
Fitment
Designed for use with -06 (3/8" ID) braided hydraulic hoses including Winner/Eaton hose series EC110, EC210, EC115, EC215, EC118, and equivalent SAE 100R1/R2 braided hoses. The 316Ti stainless steel construction is ideal for marine, wash-down, food-grade, or corrosive environments. Suitable for high-pressure hydraulic circuits in heavy construction, mining, and industrial applications.
Cross-References
- 26791-06-06Z — carbon steel equivalent (same geometry, Cr3+ plating)
- 26791-06-06 — carbon steel, no suffix (same 90° JIC -06)
- 26712-06-06RW — straight spiral hose equivalent in 316Ti stainless
FAQ
What does the RW suffix mean on Winner fittings?
The RW suffix indicates 316Ti stainless steel material. This offers significantly better corrosion resistance compared to zinc-plated carbon steel (Z suffix), making it the right choice for salt-water, marine, or chemical environments.
Is this a 2-piece or 1-piece fitting?
This is a 2-piece fitting: a separate nipple and socket that are crimped together onto the hose. The 2-piece design allows non-skive assembly for faster hose fabrication.
What braided hoses is the 26791-06-06RW compatible with?
Compatible with -06 (3/8" ID) braided hoses including Winner/Eaton EC110, EC115, EC210, EC215, and equivalent SAE 100R1AT/100R2AT hoses. Confirm crimp specifications with your hose assembly equipment manual.
Where is this fitting stocked?
In stock at AIM Rentals, Kelowna, BC. Orders placed before 2 PM Pacific ship same business day. Ships Canada-wide.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
