Winner Fluid 1CG-18-06 Hydraulic Adapter | M18x1.5 to G3/8" BSP
SKU 1CG-18-06
In stock: 2 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner Fluid 1CG-18-06 Hydraulic Adapter
OEM-spec hydraulic adapter, part number 1CG-18-06 (suffix -Z for zinc Cr3+ plating), manufactured to Winner Fluid specifications. This is a metric male 24° cone to BSP O-ring seal adapter (1CG series), connecting M18x1.5 metric thread to G3/8" BSP port. Suitable for use in construction, agricultural, and mining hydraulic systems. Stocked in Kelowna, BC and ships Canada-wide.
Specifications
- Part Number: 1CG-18-06 / 1CG-18-06Z
- Type: Hydraulic Adapter — Metric Male 24° Cone / BSP O-Ring Seal
- Metric Thread: M18x1.5 (male 24° cone)
- BSP Thread: G3/8" x 19 (with O-ring seal)
- Tube O.D.: 12 mm
- Series: L series (light duty, up to 40 MPa)
- Standard: ISO 8434-1 compatible
- Material: Carbon steel with Cr3+ zinc plating
- Stocked: Kelowna, BC — ships Canada-wide
Fitment
This adapter is a universal hydraulic fitting suitable for any hydraulic system using M18x1.5 metric 24° cone connections to G3/8" BSP ports, including:
- Construction equipment hydraulic systems
- Agricultural machinery hydraulic circuits
- Mining equipment hydraulic lines
FAQ
What is the 1CG series?
The Winner Fluid 1CG series is a metric male 24° cone body to BSP female O-ring port adapter, meeting ISO 8434-1 requirements. The suffix Z indicates standard Cr3+ zinc plating.
What is the pressure rating?
The 1CG-18-06 is an L series fitting with a working pressure of up to 40 MPa (5800 psi) at this size.
Is this a Winner Fluid branded part?
Yes. Part number 1CG-18-06 follows Winner Fluid's naming convention and is consistent with their published catalog for this fitting type.
Can I get this shipped to me in Canada?
Yes. This part ships Canada-wide from our Kelowna, BC warehouse.
