OEM-spec 20441-36-12RW 45° Metric Female 24° Cone Hose Fitting
SKU 20441-36-12RW
In stock: 6 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
The 20441-36-12RW is a 45° metric female 24° cone O-ring L.T. hose fitting, conforming to ISO 12151-2 / DIN 3865. OEM-spec replacement — a quality hydraulic hose fitting manufactured to industry standards. Zinc-plated carbon steel for corrosion resistance. Stocked in Kelowna, BC and ships Canada-wide.
Specifications
| Part Number | 20441-36-12RW |
|---|---|
| Type | 45° Metric Female 24° Cone O-Ring L.T. Hose Fitting |
| Standard | ISO 12151-2 / DIN 3865 |
| Thread | M36×2 |
| Hose Dash Size | -12 |
| Series | L.T. (Light Series, braided hose) |
| Body Angle | 45° |
| Material | Carbon steel, zinc-plated |
| O-Ring | NBR (Buna-N) |
Fitment
Compatible with hydraulic hose assemblies conforming to ISO 12151-2 / DIN 3865. Verify thread size, hose dash size, and series (L.T. or H.T.) before ordering.
FAQ
What is the part number 20441-36-12RW?
A 45° metric female 24° cone O-ring L.T. hose fitting, M36×2, dash-12, per ISO 12151-2 / DIN 3865. Used in hydraulic hose assemblies on excavators, loaders, and agricultural machines.
What does the "RW" suffix mean?
"RW" indicates a zinc-plated finish suitable for standard mineral oil hydraulic systems.
What is the difference between L.T. and H.T. series?
L.T. is for braided hoses (1SN/2SN). H.T. is for spiral hoses (4SP/4SH/R12). Match fitting series to hose construction.
Is this in stock in Canada?
Yes, stocked in Kelowna, BC, ships Canada-wide.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
