Winner Fluid 20512-24-08RW Hydraulic Fitting | M24x1.5 24° Cone 1/2"
SKU 20512-24-08RW
In stock: 8 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner Fluid 20512-24-08RW hydraulic hose fitting, metric 24° cone S-series female with M24x1.5 port thread and 1/2" (Dash 8) hose end. Manufactured to ISO 12151-2 specification for high-pressure hydraulic systems. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 20512-24-08RW
- Type: Hydraulic Hose Fitting — Metric 24° Cone S-Series Female
- Port Thread: M24x1.5 (metric)
- Hose End: 1/2" ID (Dash 8) braided or spiral hydraulic hose
- Standard: ISO 12151-2 (24° cone S-series)
- Material: Carbon steel
- Brand: Winner Fluid (OEM-spec hydraulic fitting)
Fitment
Compatible with hydraulic systems on construction, agricultural, and industrial equipment using M24x1.5 metric 24° cone S-series ports with 1/2" hose lines. Verify thread size and hose inside diameter before installation.
FAQ
- What is a 20512-series fitting?
- The Winner Fluid 20512 series are metric 24° cone S-series female fittings per ISO 12151-2. They provide a reliable, leak-free connection between hose and equipment ports in high-pressure hydraulic circuits.
- What does the -24-08 designation mean?
- "-24" indicates the M24x1.5 port thread size; "-08" indicates 1/2" (Dash 8) hose inside diameter.
- Where is this stocked?
- Available in Kelowna, BC, with Canada-wide shipping from AIM Rentals Parts.
- Is this compatible with JIC or BSP fittings?
- No. The 20512 series is a 24° metric cone fitting (ISO 12151-2) and is not interchangeable with JIC 37° or BSP fittings without an adapter.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
