Winner Fluid 24212-10-10 ORFS Female Hose Fitting -10 | 1"-14 Thread
SKU 24212-10-10
In stock: 6 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner Fluid 24212-10-10 ORFS Female Flat Seat Hose Fitting
The Winner Fluid 24212-10-10 is an ORFS (O-Ring Face Seal) female flat seat hose fitting for spiral hydraulic hose, conforming to ISO 12151-1 / SAE J516. This -10 hose size fitting features a 1"-14 UN thread and is designed for high-pressure spiral hose assemblies in heavy equipment, construction, and agricultural applications. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 24212-10-10
- Series: Winner Fluid 24212 (ORFS Female Flat Seat — Spiral Hose)
- Type: ORFS Female Flat Seat Hose Fitting
- Standard: ISO 12151-1 / SAE J516
- Thread: 1"-14 UN (ORFS)
- Hose Size: -10 (5/8" ID)
- Material: Carbon steel, zinc plated
- Compatible Hose: 4SP, 4SH, R12 spiral hydraulic hose
Fitment
Universal hydraulic fitting for use in:
- Heavy equipment hydraulic hose assemblies
- Construction machinery hydraulic systems
- Agricultural machinery hydraulic systems
- Industrial hydraulic circuits
Cross-References
- Danfoss/Eaton Winner 24212-10-10
- Winner by Danfoss 24212 series (-10 hose / -10 thread)
FAQ
What is the 24212-10-10 used for?
This ORFS female flat seat fitting connects -10 (5/8" ID) spiral hydraulic hose to equipment ports with 1"-14 UN ORFS thread. Common in excavator, loader, and crane hydraulic circuits requiring leak-free high-pressure connections.
What does the double -10 designation mean?
In Winner Fluid nomenclature, 24212-10-10 means: 24212 series, -10 hose size (5/8" ID), -10 thread end (1"-14 ORFS). Both the hose bore and end thread are the same -10 dash size.
Is this fitting compatible with 4SH spiral hose?
Yes. The 24212 series is designed for high-pressure spiral hose including 4SP, 4SH, and R12 hose types. Confirm the crimp specification for your hose OD and wall thickness.
Where is this stocked?
We stock this fitting at our Kelowna, BC facility. Orders ship Canada-wide, typically same business day.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
