Winner Fluid 24212-12-12 ORFS Female Hose Fitting -12 | 1-3/16"-12 Thread
SKU 24212-12-12
In stock: 6 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner Fluid 24212-12-12 ORFS Female Flat Seat Hose Fitting
The Winner Fluid 24212-12-12 is an ORFS (O-Ring Face Seal) female flat seat hose fitting for spiral hydraulic hose, conforming to ISO 12151-1 / SAE J516. This -12 hose size fitting features a 1-3/16"-12 UN thread, suitable for high-pressure spiral hose assemblies in heavy equipment, construction, and agricultural hydraulic systems. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 24212-12-12
- Series: Winner Fluid 24212 (ORFS Female Flat Seat — Spiral Hose)
- Type: ORFS Female Flat Seat Hose Fitting
- Standard: ISO 12151-1 / SAE J516
- Thread: 1-3/16"-12 UN (ORFS)
- Hose Size: -12 (3/4" ID)
- Material: Carbon steel, zinc plated
- Compatible Hose: 4SP, 4SH, R12 spiral hydraulic hose
Fitment
Universal hydraulic fitting for use in:
- Heavy equipment hydraulic hose assemblies
- Construction machinery hydraulic systems
- Agricultural machinery hydraulic systems
- Industrial hydraulic circuits
Cross-References
- Danfoss/Eaton Winner 24212-12-12
- Winner by Danfoss 24212 series (-12 hose / -12 thread)
FAQ
What application uses the 24212-12-12 fitting?
The -12 size is very common in excavator and loader boom and arm cylinder hydraulic circuits, as well as swing motor and travel motor hose lines. The 3/4" bore handles high flow rates typical of these applications.
What thread size is the -12 ORFS end?
The -12 ORFS thread is 1-3/16"-12 UN. The O-ring face seal groove is machined into the flat end face, sealing against the mating port or fitting to prevent leaks even at high pressures.
Can I use the 24212-12-12 on R13 or R15 hose?
The 24212 series is certified for 4SP, 4SH, and R12 spiral hose. For R13 or R15 high-pressure hose, verify the crimp ferrule compatibility with the hose manufacturer or a hydraulic specialist.
Where is this stocked?
We stock this fitting at our Kelowna, BC facility. Orders ship Canada-wide, typically same business day.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
