Winner Fluid 24212-20-20 ORFS Female Hose Fitting -20 | 1-11/16"-12 Thread
SKU 24212-20-20
In stock: 5 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner Fluid 24212-20-20 ORFS Female Flat Seat Hose Fitting
The Winner Fluid 24212-20-20 is an ORFS (O-Ring Face Seal) female flat seat hose fitting for spiral hydraulic hose, conforming to ISO 12151-1 / SAE J516. This large -20 (1-1/4" ID) hose fitting features a 1-11/16"-12 UN thread and is engineered for high-flow hydraulic circuits on excavators, loaders, cranes, and industrial equipment. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 24212-20-20
- Series: Winner Fluid 24212 (ORFS Female Flat Seat — Spiral Hose)
- Type: ORFS Female Flat Seat Hose Fitting
- Standard: ISO 12151-1 / SAE J516
- Thread: 1-11/16"-12 UN (ORFS)
- Hose Size: -20 (1-1/4" ID, DN 32)
- Material: Carbon steel, zinc plated
- Compatible Hose: 4SP, 4SH, R12 spiral hydraulic hose
Fitment
Universal ORFS hydraulic fitting. Commonly used in hydraulic hose assemblies on:
- Hitachi excavators
- Hyundai excavators
- Komatsu excavators
- Doosan excavators
- Volvo excavators
- General heavy equipment with ORFS porting
Cross-References
- 24212-20-20W (Winner stainless steel variant)
- 24212N-20-20WZ (nickel-plated variant)
FAQ
What equipment uses -20 ORFS fittings?
The -20 (1-1/4" ID) ORFS size is typical for main hydraulic pump supply and return lines, large cylinder lines, and travel motor supply lines on mid-to-large excavators and wheel loaders. Any machine with 1-11/16"-12 ORFS ports can accept this fitting.
What is the thread specification for 24212-20-20?
The end connection is 1-11/16"-12 UN (ORFS) with a flat-face O-ring groove. This is the standard -20 ORFS thread per SAE J516 / ISO 12151-1.
What spiral hose types does this fit?
The 24212 series is designed for 4SP, 4SH, and R12 four-wire spiral hydraulic hose in the -20 dash size. Confirm the crimp specification with your hose assembly equipment or distributor.
Where is this stocked?
We stock this fitting at our Kelowna, BC facility. Orders ship Canada-wide, typically same business day.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["Hitachi excavators","Hyundai excavators","Komatsu excavators","Volvo excavators","Doosan excavators"] | |||
