OEM-spec 24292-08-08 ORFS Spiral Hose Fitting | Winner-Style -8x-8
SKU 24292-08-08
In stock: 5 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
OEM-spec 24292-08-08 ORFS Spiral Hose Fitting
OEM-spec replacement for the 24292-08-08 two-piece ORFS (O-Ring Face Seal) male straight fitting for spiral high-pressure hose. Compatible with the Winner Fluid 24292 series and SAE J516 / ISO 12151-1 equivalent designs. Thread size 13/16"-16 UN, -8 hose ID. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 24292-08-08
- Series: 24292 (ORFS Male Straight, 2-piece spiral)
- Thread: 13/16"-16 UN (SAE ORFS -8)
- Hose ID: -8 (1/2 in / 12.7 mm)
- Standard: SAE J516 / ISO 12151-1
- Material: Carbon steel, zinc-plated
- Application: High-pressure spiral hose (4SP, 4SH, R9, R12)
Fitment
Suitable for -8 spiral hydraulic hose assemblies used on heavy construction, forestry, mining, and industrial equipment. Verify hose series and dash size before ordering.
Cross-References
- 24292-08-08Z (Winner Fluid variant)
- 24291-08-08 (mating socket/nut)
FAQ
What is the difference between 24291 and 24292 series?
The 24292 series is the nipple/stem half of the fitting, while 24291 is the socket/nut half. Both are needed to form a complete 2-piece hose assembly.
Is this compatible with Winner Fluid or Danfoss fittings?
Yes — this is an OEM-spec replacement designed to the same SAE J516 dimensional standard as Winner Fluid (now Danfoss) 24292 series fittings.
What hose types work with this fitting?
The 24292-08-08 suits -8 ID high-pressure spiral hose including SAE 100R9, R12, 4SP, and 4SH types.
Where is this stocked?
In stock in Kelowna, BC. Orders ship same business day (before 2 PM Pacific). Shipping included Canada-wide on most orders.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
