OEM-spec 24292-20-20RW 90° ORFS Female Swivel Spiral Hose Fitting
SKU 24292-20-20RW
In stock: 3 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
The 24292-20-20RW is a 90° ORFS female flat seal swivel spiral hose fitting, conforming to ISO 12151-1 / SAE J516. OEM-spec replacement — this is a quality OEM-spec hydraulic hose fitting manufactured to industry standards. Manufactured from zinc-plated carbon steel for corrosion resistance in hydraulic systems. Stocked in Kelowna, BC and available for shipping across Canada.
Specifications
| Part Number | 24292-20-20RW |
|---|---|
| Type | 90° ORFS Female Flat Seal Swivel Spiral Hose Fitting |
| Standard | ISO 12151-1 / SAE J516 |
| Thread | 1-11/16"-12 UNF ORFS |
| Hose Dash Size | -20 |
| Series | ORFS 90° Swivel Spiral |
| Body Angle | 90° |
| Material | Carbon steel, zinc-plated |
| O-Ring | NBR (Buna-N) |
Fitment
This industry-standard fitting is compatible with hydraulic hose assemblies conforming to ISO 12151-1 / SAE J516. Verify thread size and hose dash size against your hose assembly before ordering.
FAQ
What is ORFS?
ORFS stands for O-Ring Face Seal. It uses a flat-faced port with an O-ring groove to provide a highly leak-resistant connection (ISO 12151-1 / SAE J516). It is common in modern heavy-equipment hydraulic systems.
What is the difference between straight and 90° ORFS swivel fittings?
A 90° elbow allows hose routing to turn sharply without bending the hose, reducing stress on hose assemblies in tight equipment compartments.
What thread is 1-11/16"-12 UNF?
1-11/16"-12 UNF is the ORFS thread for dash-20 (1-1/4" ID hose). It is standardized in ISO 12151-1 and SAE J516 for heavy-equipment hydraulic systems.
Is this in stock in Canada?
Yes, stocked in Kelowna, BC, ships Canada-wide. Same-day dispatch before 2 PM PT.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
