Winner by Danfoss 26712-10-10RW JIC Female Spiral Hose Fitting | 316Ti Stainless -10
SKU 26712-10-10RW
In stock: 8 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Winner by Danfoss 26712-10-10RW JIC Female Spiral Hose Fitting — 316Ti Stainless Steel
The Winner by Danfoss 26712-10-10RW is a 2-piece crimp JIC female 37° cone swivel straight hose fitting for -10 (5/8" ID) spiral hydraulic hose. The RW suffix designates 316Ti stainless steel construction, delivering superior corrosion resistance for marine, wash-down, and chemically aggressive environments. Winner by Danfoss is manufactured to ISO 12151-5 / SAE J516. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 26712-10-10RW
- Series: Winner 26712 (2-Piece, Spiral Hose)
- End Type: JIC Female 37° Cone Swivel, Straight
- Hose Dash Size: -10 (5/8" ID spiral hose)
- Terminal End Dash Size: -10
- Thread Size: 7/8"-14 UNF
- Material: 316Ti Stainless Steel (RW suffix)
- Construction: 2-piece crimp, spiral hose application
- Standard: ISO 12151-5 / SAE J516
- Brand: Winner by Danfoss (OEM-spec)
Fitment
Designed for use with -10 (5/8" ID) spiral hydraulic hoses including SAE 100R9, 100R12, 100R13, 100R15, and compatible Winner/Danfoss spiral hose series. Suitable for high-pressure hydraulic circuits in heavy construction equipment, mining machinery, shipyard, primary metal, and wind power applications.
Cross-References
- 26712-10-10RW — Winner by Danfoss (stainless, spiral, straight)
- 26712-10-10Z — carbon steel equivalent (same geometry)
- 26711-10-10RW — braided hose equivalent (different series)
- 26791-10-10RW — 90° elbow equivalent in 316Ti stainless
FAQ
What does the RW suffix mean on Winner fittings?
On Winner by Danfoss fittings, the RW suffix indicates 316Ti stainless steel material. This provides superior corrosion resistance vs standard zinc-plated carbon steel (Z suffix) — ideal for salt-water, chemical wash-down, or high-humidity environments.
What is the difference between 26711 and 26712 series?
The 26711 series is for braided hydraulic hose (R1, R2 type); the 26712 series is for spiral (multi-wire spiral) hose (R9, R12, R13, R15 type). Match the fitting series to your hose type to ensure a proper crimp.
What thread size is the 26712-10-10RW?
The -10 terminal end uses a 7/8"-14 UNF JIC thread, conforming to SAE J514 / ISO 8434-2 37° flare standard.
Where is this fitting stocked?
In stock at AIM Rentals, Kelowna, BC. Orders placed before 2 PM Pacific ship same business day. Ships Canada-wide.
Fitment data available on request. Email sales@rentwithaim.ca with your machine year/make/model.
