Genuine XCMG 803087366 Front Wheel Steering Cylinder | GR215, GR2605
SKU 803087366
In stock: 2 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
The XCMG 803087366 is the genuine OEM front wheel steering cylinder for XCMG GR215 and GR2605 motor graders. This double-acting hydraulic cylinder converts hydraulic pressure into precise wheel steering force for reliable directional control on highways, mines, airports, and earthmoving sites. Stocked in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 803087366
- Part Name: Front Wheel Steering Cylinder (XGYG07-192)
- Type: Double-acting piston steering cylinder
- Cylinder Bore: 80 mm
- Rod Diameter: 45 mm
- Stroke: 320 mm
- Rated Working Pressure: 40 MPa
- Maximum Working Pressure: 45 MPa
- Operating Temperature: -45°C to 125°C
- Seal Material: Fluororubber (FKM)
Fitment
- XCMG GR215 Motor Grader (160 kW Cummins 6CTA8.3-C215)
- XCMG GR2605 Motor Grader (194 kW Cummins QSL8.9)
Cross-References
OEM designation: XGYG07-192. Companion steering component: XCMG steering valve OEM 803087367.
FAQ
Is 803087366 a genuine XCMG part?
Yes — confirmed by multiple XCMG parts catalogs as the front wheel steering cylinder for the GR215 and GR2605 motor graders.
What are the core dimensions?
Bore: 80 mm, rod: 45 mm, stroke: 320 mm. Rated thrust: 201 kN (rodless) / 113 kN (rod side).
Does this require any modification to fit the GR2605?
No — the 803087366 is confirmed as a direct OEM fit for the GR2605 with no modifications required.
Where is this stocked?
Stocked in Kelowna, BC. Ships Canada-wide with free shipping included.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["XCMG GR2605 Motor Grader","XCMG GR180 Motor Grader","XCMG GR215 Motor Grader"] | |||
