Genuine XCMG 803090598 Front Wheel Tilt Cylinder | GR2605
SKU 803090598
In stock: 1 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
Genuine XCMG 803090598 Front Wheel Tilt Cylinder | GR2605 Motor Grader
The XCMG 803090598 is the genuine OEM front wheel tilt cylinder (complete high-pressure actuator assembly) for the XCMG GR2605 motor grader. This cylinder converts hydraulic pressure into precise mechanical thrust to achieve ±15° front wheel tilt angle adjustment, essential for grading stability and flatness. Stocked at AIM Rentals in Kelowna, BC — ships Canada-wide.
Specifications
- Part Number: 803090598
- Type: Front Wheel Tilt Cylinder (Complete Set)
- Cylinder Bore: 63 mm
- Rod Diameter: 35 mm
- Stroke: 200 mm
- Rated Pressure: 31.5 MPa
- Temperature Range: −40 °C to 120 °C
- Protection Rating: IP65
- Material: 27SiMn alloy cylinder body, 45# chrome-plated piston rod, imported PU seals
Fitment
- XCMG GR2605 Motor Grader — front wheel steering/tilt system
Cross-References
- XCMG Assembly Module: 381200391
- Internal designation: XGYG07-193A
FAQ
What does the 803090598 cylinder do on the GR2605?
It actuates the front wheel tilt function, allowing ±15° lateral tilt adjustment to improve grader stability on slopes and uneven terrain.
Is this a genuine XCMG part or an aftermarket replacement?
This is a genuine XCMG OEM part manufactured to original factory specifications, confirmed by XCMG part number 803090598.
How long does shipping take from Kelowna, BC?
AIM Rentals ships Canada-wide. Contact us for lead times specific to your region.
Does this cylinder require modification for installation?
No. It is a direct 1:1 OEM replacement — mounting holes, pin dimensions, and connector specs match the GR2605 front wheel tilt system exactly.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["XCMG GR2605"] | |||
