XCMG 803693543 Central Electrical Box | GR2605 Motor Grader
SKU 803693543
In stock: 1 available · Ships from Kelowna BC
Verify fitment by part number before ordering.
Match the listed SKU and verified cross-references to your current part number. If fitment is not listed, send AIM Rentals the machine details and current part number before ordering.
XCMG 803693543 Central Electrical Box | GR2605 Motor Grader
The XCMG 803693543 is the original central electrical box (junction/fuse box) for the XCMG GR2605 motor grader. Confirmed as a genuine XCMG OEM part, it serves as the core hub for the entire electrical system — managing power distribution, circuit control, fuse protection, and relay switching. Stocked in Kelowna, BC and ships Canada-wide.
Specifications
- Part Number: 803693543
- Type: Central Electrical Box (HZ-DQH249)
- OEM Maker: XCMG (Xuzhou Construction Machinery Group)
- Compatible Model: XCMG GR2605 Motor Grader
- Features: Original factory assembly, integrated fuses and relays, standardized wiring, waterproof and dustproof
- Stocking Location: Kelowna, BC, Canada
Fitment
Confirmed fitment from product tags and parts catalog data:
- XCMG GR2605 Motor Grader
Confirm fit by part number with your dealer or email sales@rentwithaim.ca.
FAQ
What does the XCMG 803693543 central electrical box do?
It provides centralized management of the vehicle's power distribution and circuit control, with integrated fuses and relays protecting motors, solenoid valves, lights, instruments, and control systems from overload and short circuits.
Is 803693543 a genuine XCMG OEM part?
Yes — 803693543 is confirmed as the original XCMG OEM central electrical box for the GR2605, matching original factory layout and pin definitions for complete compatibility.
What should I check when replacing this part?
Always disconnect the power supply before replacement. Insert all plugs into the correct interfaces, secure firmly and ensure waterproofing. After installation, test all electrical functions including lights, instruments, and operating mechanisms.
Where is this part stocked?
Stocked in Kelowna, BC. Orders placed before 2:00 pm Pacific Time ship the same business day, Canada-wide.
| Make | Model | Year | Engine / Spec |
|---|---|---|---|
| ["XCMG GR2605"] | |||
